Testing Webpage: This is just the beginning of a major disaster.

Showing pictures with diferent texts, fonts and styles.

Popular Local Repeaters:

Analog VHF

Frequency Offset PL Tone

146.62 (Salt Lake County) -.600 MHz None
146.76 (Utah County) -.600 MHz None
147.12 (Intermountain Intertie) +.600 MHz 100 hz




Analog UHF

Frequency Offset PL Tone

448.400 -5 mhz 100 hz
449.425 -5 mhz 100 hz
449.725 -5 mhz 100 hz



Digital VHF

Frequency








Digital UHF

Frequency

447.9375 DMR SLC
448.075 D-Star SLC
447.975 D-Star Utah County


Full Repeater List PDF Click Here
Utah VHF Society Webpage









Getting into Digital Voice Radio

Get your radio. These links are specific to the Anytone 878 (Most Popular radio) The concept is the same for all DMR radios.
I will get all Modes posted here with the Radios that I have on hand like the MD-380 (DMR) and the Kenwood D74 (D-Star)
Yaesu 991A (C4FM - Fusion)

https://www.amazon.com/gp/product/B07RL8GYJ6/ref=ppx_yo_dt_b_asin_title_o02_s00?ie=UTF8&psc=1

Register for a DMR Radio ID
https://www.radioid.net/register#!

Download and install the code plug from here. Read the instructions for your radio.
https://www.dmr-utah.net/codeplugs
https://www.dmr-utah.net/

Latest Firmware (watch the instruction video)
868 and 878 firmware

MMDVM Hotspot from Amazon. It's up to you which one you get.
https://www.amazon.com/gp/product/B07BTS738L/ref=ppx_yo_dt_b_asin_title_o01_s00?ie=UTF8&psc=1

Hot Spot and DMR Set up.
https://www.youtube.com/watch?v=N60ho7SQ48M

Downloadable Contact List for the Anytone 878 (Read instructions)
https://kf5iw.com/

If you go with another brand of Radio or different kind of Hotspot, ZUMspot, OpenSpot etc. Please search the net for other videos for that particular version. I will post instructions on the TYT MD380 soon. Since I have both radios and I have programed them both successfully and have written Code Plugs for both I have little knowledge.
Have fun.

Denzii

In DMR Channels are called Talk Groups. The most used are 3100 (USA) and 91 (Worldwide)
In D-Star Channels are called Reflectors. The most used are 030C (Nationwide) and 001C (Worldwide)
In Fusion Channes are called Rooms. The most common is America link. (Nationwide - world)

To link to these channels will be writen in each Instruction page when I get this all set up. You can do searches on the internet now. If you come across any information that will help others get into Digital and want it added to this web page then please email me at KD3NZI@denzii.com
